Republic P-47

Republic P-47B-RA (S/N 41-5905). (U.S. Air Force photo)

Republic P-47B-RA (S/N 41-5905). (U.S. Air Force photo)

Republic P-47B-RA (S/N 41-5931) in flight. (U.S. Air Force photo)

Republic P-47B-RA (S/N 41-5931) in flight. (U.S. Air Force photo)

Republic P-47B-RA in flight. (U.S. Air Force photo)

Republic P-47B-RA in flight. (U.S. Air Force photo)

Republic P-47C-5-RE (S/N 41-6601). (U.S. Air Force photo)

Republic P-47C-5-RE (S/N 41-6601). (U.S. Air Force photo)

Republic P-47C-2-RE (S/N 41-6182). (U.S. Air Force photo)

Republic P-47C-2-RE (S/N 41-6182). (U.S. Air Force photo)

Republic P-47D-25. (U.S. Air Force photo)

Republic P-47D-25. (U.S. Air Force photo)

Republic P-47D-30-RE (S/N 44-90021). (U.S. Air Force photo)

Republic P-47D-30-RE (S/N 44-90021). (U.S. Air Force photo)

Republic P-47D-40-RE (S/N 44-90386) in flight firing rockets. (U.S. Air Force photo)

Republic P-47D-40-RE (S/N 44-90386) in flight firing rockets. (U.S. Air Force photo)

Republic P-47D 5-ship formation (Y36 is P-47D-21-RA, S/N 43-25372). (U.S. Air Force photo)

Republic P-47D 5-ship formation (Y36 is P-47D-21-RA, S/N 43-25372). (U.S. Air Force photo)

Republic XP-47E (S/N 41-6065). (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 10 of 24

Republic XP-47E (S/N 41-6065). (U.S. Air Force photo)

Republic P-47G-1-CU (S/N 42-24964) on skis. (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 11 of 24

Republic P-47G-1-CU (S/N 42-24964) on skis. (U.S. Air Force photo)

Republic P-47G-5-CU (S/N 42-25032). (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 12 of 24

Republic P-47G-5-CU (S/N 42-25032). (U.S. Air Force photo)

Republic XP-47H (S/N 42-23297). (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 13 of 24

Republic XP-47H (S/N 42-23297). (U.S. Air Force photo)

Republic XP-47H 3/4 front view. (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 14 of 24

Republic XP-47H 3/4 front view. (U.S. Air Force photo)

Republic XP-47H in flight. (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 15 of 24

Republic XP-47H in flight. (U.S. Air Force photo)

Republic XP-47J. (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 16 of 24

Republic XP-47J. (U.S. Air Force photo)

Republic XP-47J. (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 17 of 24

Republic XP-47J. (U.S. Air Force photo)

Republic XP-47J. (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 18 of 24

Republic XP-47J. (U.S. Air Force photo)

Republic XP-47K (S/N 42-8702). (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 19 of 24

Republic XP-47K (S/N 42-8702). (U.S. Air Force photo)

Republic YP-47M (S/N 42-27385) instrumented for flight test on July 28, 1945. (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 20 of 24

Republic YP-47M (S/N 42-27385) instrumented for flight test on July 28, 1945. (U.S. Air Force photo)

Republic P-47M-1 (S/N 42-21159). (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 21 of 24

Republic P-47M-1 (S/N 42-21159). (U.S. Air Force photo)

Republic P-47N-5 3/4 front view (S/N 44-88335, second block, five aircraft built). (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 22 of 24

Republic P-47N-5 3/4 front view (S/N 44-88335, second block, five aircraft built). (U.S. Air Force photo)

Republic P-47N-5 three ship formation (S/N 44-88576, 88589, 88577). (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 23 of 24

Republic P-47N-5 three ship formation (S/N 44-88576, 88589, 88577). (U.S. Air Force photo)

Republic P-47. (U.S. Air Force photo)
PHOTO DETAILS  /   DOWNLOAD HI-RES 24 of 24

Republic P-47. (U.S. Air Force photo)

Affectionately nicknamed "Jug," the P-47 was one of the most famous AAF fighter planes of World War II. Although originally conceived as a lightweight interceptor, the P-47 developed as a heavyweight fighter and made its first flight on May 6, 1941. The first production model was delivered to the AAF in March 1942, and in April 1943 the Thunderbolt flew its first combat mission -- a sweep over Western Europe. Used as both a high-altitude escort fighter and a low-level fighter-bomber, the P-47 quickly gained a reputation for ruggedness. Its sturdy construction and air-cooled radial engine enabled the Thunderbolt to absorb severe battle damage and keep flying. During WWII, the P-47 served in almost every active war theater and in the forces of several Allied nations. By the end of WWII, more than 15,600 Thunderbolts had been built.

Production P-47B, C, early D and G series aircraft were built with metal-framed "greenhouse"-type cockpit canopies. Late D series (dash 25 and later) aircraft and all M and N series production aircraft were given clear "bubble" canopies, which gave the pilot improved rearward vision.

The National Museum of the United States Air Force has a P-47D-15-RE and a P-47D-40-RA on display.


Type Number built/
converted
Remarks
XP-47 0 Lt. interceptor (canceled)
XP-47A 0 Modified XP-47; no guns or radios
XP-47B 1 Improved P-44 and XP-47 design
P-47B 171 First prod. aircraft; eight .50-cal. in wings
P-47CC 602 Improved P-47B
P-47D-RE 3,963 Razorback P-47D; Blocks 1-22
P-47D-RE 2,546 Bubble canopy P-47D; Blocks 25-30
P-47D-RA 2,350 Evansville, Ind., plant; Blocks 2-23
P-47D-RA 3,743 Evansville bubble canopy; Blocks 26-40
XP-47E 1 (cv) Modified B (171st built); press. cockpit
XP-47F 1 (cv) Modified P-47B; laminar flow wing
P-47G-CU 354 Curtiss-built D model
XP-47H 1 (cv) Modified P-47D; 16-cylinder Chrysler engine
XP-47J 1 New model; six .50-cal.
XP-47K 1 (cv) Modified P-47D with Hawker Typhoon Cnpy.
XP-47L 1 (cv) Modified P-47D-20
YP-47M 3 (cv) Modified P-47D; dive brakes
P-47M 130 High-speed version
XP-47N 1 Improved D; new wing
P-47N-RE 1,667 Long-range escort model
P-47N-RA 149 5,934 canceled after VJ-Day


TECHNICAL NOTES (P-47D):
Armament: Six or eight .50 cal. machine guns and either 10 rockets or 2,500 lbs. of bombs
Engine: One Pratt & Whitney R-2800-59 of 2,430 hp
Maximum speed: 433 mph
Cruising speed: 350 mph
Range: 1,030 mi.
Service ceiling: 42,000 ft.
Span: 40 ft. 9 in.
Length: 36 ft. 2 in.
Height: 14 ft. 8 in.
Weight: 17,500 lbs. maximum
Crew: One
